Model IR-0714-2 IR-0714-3 IR-0714-4
Type 2 wire 3 wire 4 wire
Alarm Contact N/A N/A 0.8A @ 30V DC, 0.4A @125V AC
Sensor Type Single IR
Wavelength 4.35μm
Standby Current under 200μA @24V DC 470Ω
Voltage Range 12V～30V DC
Alarm Current 35mA @24V DC 470Ω
Ambient Temperature -10℃～+55℃
Material Fire-proof plastic
Dimensions 102 mm (Dia.) × 38 mm (H)
Weight 130g (2 wire & 3 wire) / 145g (4 wire)
Color White
